SNORKEL TELESCOPIC BOOM LIFTS — TB80
HIGHLY CAPABLE
The Snorkel TB80 telescopic boom lift reaches high on rough terrain. A powerful 4-wheel drive and superb ground clearance are well-suited for construction applications. Narrow dimensions and proportional controls make the TB80 easy to navigate throughout tough jobsites.
FEATURES
• Snorkel Guard™ secondary guarding system
• Four wheel drive, steer and crab steer
• Hydraulic platform rotation
• 360° continuous turntable rotation
• Drive motion alarm
• Flashing amber light
• Foam filled lug tires
• Proportional drive, boom lift, swing & extend
• Rheostat control for jib & platform level
• Power line to platform
• 3.5° tilt alarm
• Tri-entry platform
• Dual lanyard attachment points
• Hour meter & on-board diagnostics display
• Horn
• 2 year parts & labor, 5 year structural warranty
OPTIONS
• Special paint colors
• Airline to platform
• AC generator 110V/2.5kW
• Non-marking tires
• Cold weather package
• Extreme cold weather package
• Extreme environment package
• Light package
• Tow kit
• Dual fuel
• Glazier package
• Utility package
• 12kW generator package
• 12kW generator/welder package
• Environmental hydraulic oil
• Tool tray
• Pipe rack
• Personal fall arrest system
• Snorkel OnSite™ telematics
ACCESSORY PACKAGES
• 12k Generator/Welder Package
• Cold Weather Package
• Extreme Cold Weather Package
• Extreme Environment Package
• Generator Package
• Glazier Package
• Lights Package
• Tow Kit
• Utility Package
Specifications are subject to change without prior notice. Similar models may be shown in addition to the featured model. Equipment may be shown with options.
- Specifications - Power source: Kubota V2403 65hp diesel - Tier 4 Final
- Specifications - Tires: 15 x 625 foam filled lug
- Specifications - Drive system: 4 wheel drive
- Specifications - Overall length: 38 ft 8 in
- Specifications - Max. platform height: 80 ft
- Specifications - Platform capacity (SWL): 500 lbs
- Specifications - Gradeability: 40%
- Specifications - Max. drive speed (elevated): 0.6 mph
- Specifications - Controls: Proportional joystick
- Specifications - Raise / lower time: 70/65 sec
- Specifications - Overall width: 8 ft 6 in
- Specifications - Max. horizontal reach: 71 ft 2 in
- Specifications - Max. wind speed: 28 mph
- Specifications - Outside turning radius: 15 ft 6 in
- Specifications - Max. drive speed (stowed): 3.0 mph
- Specifications - Platform size: 8 ft x 3 ft
- Specifications - Platform rotation: 170°
- Specifications - Stowed height: 9 ft 6 in
- Specifications - Superstructure rotation: 360° continuous
- Specifications - Max. drive height: 80 ft
- Specifications - Ground clearance: 13 in
- Specifications - Inside turning radius: 7 ft 10 in
- Specifications - Weight: 36,332 lbs
- Specifications - Max. working height: 86 ft
- Specifications - Tailswing: 78.5 in
