EPicker Electric Walkie Straddle Stacker Electric Pallet Stackers

EPicker Electric Walkie Straddle Stacker Electric Pallet Stackers

Of all the types of equipment you can use to move or lift pallets, the ePicker Walkie Straddle Stackers deliver the most capability per dollar.  Available in capacities of 2,500, 3000 and 4000 pounds, ePicker straddle stackers can lift pallets as high as 177 inches while operating adjust half a cost of a comparable sit-down forklift.  The ePicker straddle stackers weigh just half of what they can lift, reducing both wear and tear on components and danger to personnel in the area of operation.
Whether you need one versatile lift truck or need to supplement an existing fleet, pound for pound the ePicker Walkie Straddle Stacker offers exceptional value.  Walk and get the job done for less with an ePicker Walkie Straddle Stacker.

  • :
  • Drive: 24-Volt permanent magnet DC drive motor withrare earth neodymium magnets increases efficiency and duty cycle.
  • Electrical: Curtis travel control provides smooth step less travel. Quick disconnect EPD power cut off and battery discharge indicator are standard equipment.
  • Frame and Straddles Legs: All steel construction welded rigid steel chassis for added durability. Adjustable forks on ITA style carriage. Forks are adjustable from 8” to 29.5” OD. Standard fork is 42” long x 4” wide x 1.5” thick
  • Brakes: Electro-magnetic disc brakes.
  • Serviceability: Removable one piece power head cover allows for easy maintenance.
  • Hydraulics: Lift cylinder is hard chrome. Permanent magnet pump motor and chrome plated lift cylinder provides smooth lifting and lowering. Pump unit includes DC motor, solenoid, and gear pump.
  • Tiller Arm Control: Offset steering arm provides excellent line of sight for operators. Right angle stacking in aisles as narrow as 60”.
  • Mast: ES10-62 has a non-telescoping mono mast with single lifting chain and adjustable mast rollers. Chrome plated lift cylinder provides smooth lift/lower operation and long life.
